Slamtec RPLIDAR S2L 2D Lidar 360 Degree 18 Meters Scanning Radius IP65 Proof LIDAR Sensor Scanner for Obstacle Avoidance and Navigation of Robots Support ROS/ROS2
$299.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by cdu-ruwer.de
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$299.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by cdu-ruwer.de
Free 30-day returns Details
Product details
| Management number | 227758693 | Release Date | 2026/05/09 | List Price | $119.60 | Model Number | 227758693 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- [Excellent Ranging Accuracy] Models: S2M1-RxL; Range Radius: 18 meters; Power Supply: 5V; Scan Rate from 8-15Hz; ; Power Consumption> 2W; Communication Interface:URAT Serial (1M); The height of the scanning optical area of RPLIDAR S2L is only 18mm, which make it easy to be embedded. Weight:190g, Size: 77 x 77 x 38.85mm.
- [Resistance to Strong Sunlight] Slamtec S2L Ridar Workable in both Indoor and Outdoor,even in 80Klux strong sunlight interference.Achieve stable ranging and high-precision mapping.Output high-quality point cloud data to capture more environmental details.
- [IP65 Protection Class] Slamtec S2L Sensor with a closed independent cover, it can fully protect the internal rotating mechanism, avoid external interference, ensure a stable working environment, and meet the application of industrial scenarios.
- [No-brush Motor & Lower Noise] Abandoning the belt drive in the first generation, using the self-designed no-brush motor, reducing the mechanical friction during operation, the operation is very smooth, and there is almost no noise. 32000 Times Sample Rate, make more environmental details to be retrieved during the mapping and navigation process.
- [Wide Range of Applications] Widely used in service robot navigation and obstacle avoidance, AGV vehicle obstacle detection and avoidance, parking space detection, multi-touch and large screen interaction, environmental scanning and 3D reconstruction, drone mapping and obstacle avoidance.
| ASIN | B0BGXXTXSB |
|---|---|
| Model | S2M1-RxL |
| Brand Name | WayPonDEV |
| Style Name | Modern |
| Unit Count | 1.0 Count |
| Item Weight | 190 Grams |
| Output Type | Digital |
| Part Number | Slamtec RPLIDAR S2L |
| Manufacturer | WayPonDEV |
| Material Type | Plastic |
| Mounting Type | Flange Mount |
| Current Rating | 400 Milliamps |
| Item Dimensions | 3.03 x 3.03 x 1.54 inches |
| Measuring Range | 0.05 - 18 meters |
| Sensing Distance | 18 Meters |
| Measurement Accuracy | +/- 30mm |
| Maximum Supply Voltage | 5 Volts |
| Smart Home Compatibility | Not Smart Home Compatible |
| Upper Temperature Rating | 50 Degrees Celsius |
| Specific Uses For Product | Robotics, navigation, obstacle avoidance, environmental scanning, 3D reconstruction, AGV vehicle obstacle detection and avoidance, parking space detection, multi-touch and large screen interaction |
